12.1 Inch Touchscreen Portable Patient Monitor Signs ECG NIBP SPO2 Temp
$ 271.93
Description
Packing List: Package List: 1×Patient Monitor 1×EKG Lead wire 1×NIBP Cuff 1×NIBP Extension Cable 1×SpO2 Sensor 1×Temp Sensor 1×Ground Cable 1×Power Cable 5×Electrode 2×Fuse 1×User Manual(CD) Description: This Patient Monitor can monitor parameters such as ECG, RESP, SpO2, PR, NIBP and TEMP . It integrates parameter measuring modules,display and recorder in one device,featuring in compactness,lightweight and portability. Replaceable built-in battery facilitates transportation of patient. Standard configuration: ECG, NIBP, SPO2, TEMP, RESP,PR Specification: ECG Lead Mode : 5 Leads ( R, L, F, N, C or RA, LA, LL, RL,V) Lead selection : I, II, III, avR, avL, avF, V, Waveform : 2 ch Lead mode : 3 Leads ( R, L, F or RA, LA, LL) Lead selection : I, II, III, Waveform : 1 ch Gain : ´ 2.5mm/mV, ´ 5.0mm/mV, ´ 10mm/mV, ´ 20mm/mV, auto HR and Alarm Range: Adu lt: 15 ~ 300 bpm Neo/Ped : 15 ~ 350 bpm Accuracy : ± 1% or ± 1bpm,which great Resolution : 1 bpm Sensitivity : > 200 (uV P-P) Differential Input Impedance : > 5 MΩ RESPARATION : Method : Impedance between R-F(RA-LL) Differential Input Impedance : >2.5 MΩ Measuring Impedance Range:0.3~5.0Ω Base line Impedance Range:0 – 2.5 KΩ Bandwidth : 0.3 ~ 2.5 Hz Resp. Rate Measuring and Alarm Range Adult : 0 ~ 120 rpm Neo/Ped : 0 ~ 150 rpm Resolution : 1 rpm Accuracy : ± 2 rpm Apean Alarm : 10 ~ 40 S NIBP Method : Oscillometric Mode : Manual, Auto, STAT Measuring Interval in AUTO Mode 1, 2, 3, 4, 5, 10, 15, 30, 60, 90, 120, 180, 240,480 (Min) Measuring Period in STAT Mode : 5 Min Pulse Rate Range : 40 ~ 240 bpm Alarm Type : SYS, DIA, MEAN Measuring and alarm range : Adult Mode SYS : 40 ~ 270 mmHg DIA : 10 ~ 215 mmHg MEAN : 20 ~ 235 mmHg Pediatric Mode SYS : 40 ~ 200 mmHg DIA : 10 ~ 150 mmHg MEAN : 20 ~ 165 mmHg Neonatal Mode SYS : 40 ~ 135 mmHg DIA : 10 ~ 100 mmHg MEAN : 20 ~ 110 mmHg Overpressure Adult Mode : 297 ± 3 mmHg Pediatric Mode : 240 ± 3 mmHg Neonatal Mode : 147 ± 3 mmHg SpO2 Measuring Range : 0 ~ 100 % Alarm Range : 0 ~ 100 % Resolution : 1 % Accuracy : 70% ~ ± 2 % 0% ~ 69% unspecified Actualization interval : about 1 Sec. Alarm Delay : 10 Sec. Pulse Rate Measuring and Alarm Range : 0~254bpm Resolution : 1bpm Accuracy : ± 2bpm I.5TEMP measurement : Channel : 1 Measuring and Alarm Range : 0 ~ 50 ° C Resolution : 0.1 ° C Accuracy : ± 0.1 ° C Actualization interval : about 1 Sec. Average Constant : < 10 Sec. Package List: 1×Patient Monitor 1× EKG Lead wire 1 × NIBP Cuff 1 × NIBP Extension Cable 1 × SpO2 Sensor 1 × Temp Sensor 1 ×Ground Cable 1 ×Power Cable <> <> 5 × Electrode 2 ×Fuse 1 ×User Manual(CD) <> <> Shipping A complete and correct shipping address is essential. Customers with shipping addresses outside of the U.S. are responsible for all duties and import taxes. Please contact your customs for information Return Policy All items are in brand new condition unless specified. FDA declaration: The sale of this item may be subject to regulation by the U.S. Food and Drug Administration and state and local regulatory agencies. If so, do not bid on this item unless you are an authorized purchaser.If the item is subject to FDA regulation, we will verify your status as an authorized purchaser of this item before shipping of the item.All of our products are CE approved. Please kindly check the copy of the certificate in the listing below.(Leezoe-China-Beijing-86-15963302815) This item has been cleaned and treated according to the manufacturer's instructions. 510(K)Number: K161892 Contact Us Any questions, please contact us through eBay message or e-mail, We will reply within 1-2 business days (public holidays not included). working time: Monday - Friday 9:00 AM - 5:30PM (Beijing)
