HM Series Floor Mount Spring Vibration Isolator 250-350lb Load HMLE-1-105

Description

B-LINE VIBRA TROL HMLE-1-105 HM SERIES DEFLECTION FAIL SAFE LOWER PROFILE FLOOR MOUNT VIBRATION ISOLATOR 3-3/4" H x 2-1/2" W SPRING ISOLATOR 250 to 350 LB LOAD 1" DEFLECTION Features: - HM series housed spring mounts are utilized to isolate floor mounted equipment where transmission of noise and vibration below 1200 rpm is apparent - This type of mount is most commonly used to support equipment on upper floors where structural deflection may occur - Telescopic two-piece cast iron housing to stabilize spring where external motion may occur - Slotted mounting holes on base with skid resistant pad - Mounting is facilitated by an adjustable leveling bolt - Springs are color coded for load identification - Housing components are isolated by rubber acoustical pads - Larger capacity mountings are available - Acoustical non-skid neoprene pad - Adjust mount for minimum 1/4 to 1 in operating clearance - Stable steel spring - 3/8 in Dia external adjusting and leveling bolt - 51/8 in L
