Inch Reading Dial Indicator Internal Chamfer Gage - Precision Measurement for Ch

Description

Menu Other Items Feedbacks About Us Contact Us Add To Favorites Inch Reading Dial Indicator Internal Chamfer Gage - Precision Measurement for Chamfered Holes - 0-1" Range, 001" Graduation, 0-90 Angle - 683-3Z No Setting Needed - When the three-blade plunger is pressed against a flat surface, the gage should read the set number stamped on the back of the indicator. This means you'll save time and hassle when taking measurements. Precision Fit - Our Internal Chamfer Gages are essential for ensuring a precise fit between mating parts. By measuring the chamfer diameter, you can determine if it falls within the acceptable tolerance range and make any necessary adjustments. Easy to Measure - This tool makes easy to measure the largest diameter of any chamfer that falls within the range of angles printed on the dial face. No need to guess or try to remember complicated measurements - our gages take the guesswork out of the pr Industry Leading Quality - Starrett gages are built to last, with an industry leading quality that you can trust. All ground surfaces are of hardened tool steel with a deluxe padded case. The Standard for Excellence - Proudly made in the USA, Starrett combines over 140 years of American heritage and innovation with globally sourced materials to deliver exceptional quality tools and products. These gages directly measure the diameter of chamfered holes. No setting master is necessary. When the three-blade plunger is pressed against a fl at surface, the gage should read the set number stamped on the back of the indicator. In case of wear, the gage may be adjusted to read the proper number. 0-1" Range In case of wear, the gage may be adjusted to read the proper number. Indicators are precise gages that visually show movement, typically in very small increments. Among many applications, they are used on fixtures for repetitive inspection or attached to a machine for adjustment. Starrett offers a variety of each of the major classes; mechanical dial, electronic display, lever style test and back plunger. Each type has its own unique strengths. Electronic indicators can output data. Analog dial indicators are easy to comprehend visually. Indicator requirements are very specific and Starrett offers everything you need a broad line of each indicator type, an extensive range of accessories to configure and position the gage, and as needed, an indicator-based, custom engineered solution. Resolution varies from 0.001" to 0.00005". Item Specification Item model number 683-3Z Material Alloy Steel Range 0-1" Measurement Accuracy +/-0.001 inches Is Discontinued By Manufacturer No Package Dimensions 9.49 x 7.68 x 2.2 inches; 1.43 Pounds Size Under 3 Inches Dimensions Shipping Returns Additional Info Product Dimensions: 7.68 inches x 9.49 inches x 2.2 inches. Weight: 1.43 lb Fast shipping is very important for us. Our standard shipping service is FREE. Your order will be shipped within 1-3 business days upon full payment received. Most items are delivered within 3-5 business days, however, please allow 3-10 business days. We are shipping only to USA. We only ship to the confirmed Paypal address. We reserve the right to cancel any order for any reason at any time. We are not responsible for undeliverable addresses. We offer a 30 day return policy from checkout winning date. Your satisfaction is guaranteed! If for any reason you are unhappy with your item, just return it within 30 days for a full refund, minus shipping cost. Please contact us prior to initiating a return so that we can issue you a refund authorization. Items defective upon receipt must be packaged in their retail packaging as if new and returned with a detailed description of the problem. Return shipping fees are not refundable. We reserve the right to decline any returns if the above guidelines are not followed. All of our items, unless otherwise stated, will only run on 120 volts. Please check to make sure your country complies with these specifications. If you have a problem or question regarding your transaction please contact us before leaving any type of feedback. We will work with you to resolve any problem you may have.
