K-0650 Air Compressor Cylinder Sleeve & Ring Rebuild Kit
$ 11.27
Description
Fitment: Compatible with both the single cylinder oil-free pumps and the twin cylinder oil-free pump, fits for DeVilbiss, for Porter Cable, for Sears Craftsman, for Snap On, for Ex-Cell, for Air America, for Charge Air Pro, for Grainger, for Stanley Black, for Decker and many other privately labeled air compressors. Fits model number 165080. Features: 1) When your compressor runs so loud or does not build pressure, please use this compressor ring kit to fix it, our high quality ring kit will fix the problem and make the compressor working like a new one 2) Extremely easy to install the kit, just take the cylinder system apart, the new sleeve has a rolled bottom so you need to remove the piston from the shaft and slide it up over piston, put the ring on piston before inserting into sleeve will be easier. 3) Made of high class quality steel and rubber, the cylinder sleeve is hardened to ensure tough and high pressure withstand, and it’s rustproof and corrosion resistance. The piston ring and sleeve O-rings are made of specific rubber, they will seal the cylinder and provide a great airtightness to ensure minimum loss of gases. They are very durable that could serve for many years. Installation Guide: Step 1. Uninstall the parts as direction: fill pipe-top cylinder head- valve plate assembly-cylinder sleeve- belower fan- piston rod. Step 2. Install the piston ring on the piston rod. Step 3. Insert the piston rod into the sleeve. Step 4. Attach the piston on the shaft and tight the screw. Step 5. Replace the both sleeve o rings on the valve plate assembly, then cover to the piston back. Step 6. Torque the cylinder head on and install the other parts back as direction. Package included: 1 x D25837 Coated Cylinder Sleeve 1 x DAC-308 Coated Oil Free Piston Ring 1 x SSF-3158-1 Piston Rod Cap Screw 1 x SSG-8156 Valve Plate to Cylinder Sleeve O-Ring 1 x ACG-45 Cylinder head to Valve Plate O-Ring
Tool came in quick, but had an issue with it so reached out to seller and almost immediately was given option for another tool or full refund. I asked if I needed to send the tool back and they responded already refunded not necessary to send back. Service is impeccable highly recommend.
Looks to be a quality gasket. Packaging allowed for some minor bending of the gasket during shipping. Shipping took longer than most EBay orders. Otherwise all good.
Good communication, thanks, but I ordered wrong part , didn't realize until I took everything apart, but it was not a problem, it was taken care of right away.
