NEW G2R-1-S 24VDC (S)OMRON-Relay electromagnetic
$ 4.89
Description
NEW G2R-1-S 24VDC (S)OMRON-Relay electromagnetic. Manufacturer OMRON. Type of relay electromagnetic. Relay variant industrial, miniature. Coil resistance 1.1kΩ. Coil current 21.8mA. Specification PN G2R-1-S-24 Manufacturer OMRON Type of relay electromagnetic Contacts configuration SPDT Rated coil voltage 24V DC Contact current max. 10A AC contacts rating @R (at resistive load) 10A / 250V AC DC contacts rating @R (at resistive load) 10A / 30V DC Switched voltage max. 125V DC, max. 380V AC Relay variant industrial, miniature Mounting socket Manufacturer series G2R-1-S Body dimensions 29x13x35.5mm Coil resistance 1.1kΩ Operate time 15ms Release time 5ms Coil current 21.8mA Switching capacity 300W, 2.5kVA Contact resistance 30mΩ Coil power consumption 530mW Terminal pitch 5.2mm Operating temperature -40...70°C
