Weishi 1900 Watch Timegrapher Timing Machine for Automatic & Mechanical Watches

Description

Product Detail: Note：If you have any questions, please contact us before open any case, we promise will solve the problem for you. Thanks！ Specifications: Main material: ABS Supply Voltage: AC 100V-240V 50/60Hz Measuring possibilities: rate deviation, amplitude, be-at error of mechanical watches and diagram recording of the be-at noise. Rate deviation measurement: Measuring ranges: ±999s/d or ±99.9s/d Resolution: 1.0s/d or 0.1s/d Amplitude measurement: Measuring ranges: 100°~360° Resolution: 1° Measuring of the be-at error: Measuring ranges: 0.0~9.9 ms Resolution: 0.1 milliseconds Lift angle: Measuring ranges: 30°~70° Default value: 52° Measure positions: 1-6 positions Line length: 480 points Measuring times periods: 2/4/6/8/12/20/30/60 seconds Language: Chinese, English, Japanese Display: color LCD graphic monitor, 480*272 pixels Working environment: 10℃~40℃ Relative humidity: 0~80% RH Item size: 185 * 120 * 40mm / 7.3 * 4.7 * 1.6in Item weight: 337g / 11.9ounce Package size: 230 * 210 * 195mm / 9.1 * 8.3 * 1.6in Package weight: 1379g / 3.0lb Automatic: The following beat numbers are selected by automatic selection mode：12000、14400、18000、19800、21600、25200、28800、36000、43200。 （If the tested beat is not in automatically selection, the instrument will display the closest beat number, but the test result is not correct. At this time, use the manual mode to select the relative beat.） Manual selection： It can selected out the beat number that Automatic select can not identify and rare beat number. The following beat are selected by Manual selection mode: 3600、6000、7200、7380、7440、7800、9000、9100、10800、11880、12000、12342、12480、12600、13320、13440、13500、14000、14040、14160、14200、14280、14400、14520、14580、14760、14850、15000、15360、15600、16200、16320、16800、17196、17258、17280、17786、17897、18000、18049、18514、19332、19440、19800、20160、20222、20944、21000、21031、21306、21600、25200、28800、32400、36000、43200. Feature: The frequency diagram of the watch can be displayed on the LCD screen. According to different watches, the instrument will automatically adjust the optimal signal level during the test. The instrument will automatically calculate the rate deviation, amplitude, be-at error, and display them by the data in real time; select "±99.9s/d" at item rate ranges for result display, which can make the accuracy of rate deviation up to 0.1s/d. For the conventional be-at, the instrument can automatically respond; for the special be-at, can manually select. The sampling period can be selected by 2 seconds, 4 seconds, 6 seconds, 8 seconds, 12 seconds, 20 seconds, 30 seconds, 60 seconds, and the average value of corresponding period will be regarded as the precise value of the watch. Six kinds of testing positions can be adjusted, and the simulation sound can be played in the speaker or mute. Package Included : 1 * Timegrapher 1 * Timegrapher Sensor 1 * Adapter (US/UK/EU/AU) 1 * User Manual Note: 1. Please allow minor deviation due to manual measurement. 2. Due to the difference between different monitors, the picture may not reflect the actual color of the item. 3. Communication is the best way to solve the problem. If you have any problems after purchasing, please contact us in time, before opening return or case. Payment: We accept PayPal ONLY currently. Payment must be made within 3 business days. Shipping: 1. Item will be shipped within 1-5 business days from CN Stock or US Stock according to the item location. 2. Sometimes the ship date will be delayed due to a shortage. We will inform you via message. 3. Please leave available address and phone # in delivery information. Seller are not responsible for wrong address. 4. Please indicate your personal requirement such as colors, packages, value of declaration etc. at PayPal's message when make payment. 5. We will NOT responsible for any delay during delivery including but not limited to customs postage checking, strike, force measure etc. Customs Declaration: Import duties, taxes and charges are not included in the item price or shipping charges. These charges are the buyer’s responsibility. Please check with your country’s customs office to determine what these additional costs will be prior to biddingying. Return & Refund: Returns are accepted within 30 days. Please read the item description and check the pictures carefully before bidding. Return or refund is available only if item DOA or there's error in item description causing the item not fitting your need. In such cases, seller pays for all related shipping cost if any. Returns are also acceptable if buyer purchased this by mistake and item still in good condition for reselling. Buyer is responsible for all related shipping cost. Feedback: As long as you are happy with your purchase, please kindly leave us for it is very important for our store performance. If there is any problem with your order, please contact us and give us a chance to resolve your problem Before leaving us a negative feedback.
